CURRENCY DISCRIMINATION COUNTER SB-7 (SB-1050) SERVICE MANUAL
- 33 -
MODE
CODE [ ***** ]
6
1
9 MENU
▼
If ‘▼’ is pressed, the detail on shading of each
currency is displayed.
To skip, press ‘9’.
After check shading result, press clear button.
If you want to move previous Level, press ‘9’.
The message ‘WAIT . . ABOUT
5 SEC’ is disappeared and
then shading sheet is pushed
out.
If shading of each currency is
done normally,
OK is displayed.
Wait.
SERVICE MENU1
1. ERROR STOP CTRL.
2 .SENSOR LEVEL
3. SYSTEM REPORT
4. SET A/S CALL No.
5. SET MACHINE S/N
6. SHADING_______________
7. SENSOR SELECT
SHADING
1. UV SHADING__________
2. MR SHADING
3. IR SHADING (WHITE)
4. IR SHADING (DARK)
UV SHADING
USD OK
EUR OK
(▼ KEY TO SEE NEXT)
UV SHADING
WAIT . . ABOUT 5 SEC
UV SHADING – USD
123 456 789
UV(OK – 507) 507
SUVT(OK – 210) 210
(▼ KEY TO SEE NEXT)
