SBM SB-7 - Page 55

CURRENCY DISCRIMINATION COUNTER SB-7 (SB-1050) SERVICE MANUAL
- 55 -
720509701A CASE_DETECTOR ( W/ Filter x 2EA) 1 O
O
X
720509701A CASE_DETECTOR (W/ Dummy x 2EA) 1 X
X
O
6600G002XA SUV_FILTER (375nm, D7*2.5T) 1 O
O
X
6600G005XA UV_FILTER(N) (420nm, D7*2.5T) 1 O
O
X
720512401A DUMMY_MRA 1 X
X
O
7801G025XB UV_FILTER_DUMMY 2 X
X
O
720507401A OPEN_HOOK_L_P 1 O
O
O
720507501A OPEN_HOOK_R_P 1 O
O
O
720509001A GUIDE_LOWER 1 O
O
O
7805A044XA PIVOT_HINGE_LOWER 2 O
O
O
720511301A GUIDE_RACK 1 O
O
O
720511401A RACK_L 1 O
O
O
720511501A RACK_R 1 O
O
O
720509101A GUIDE_PINCH_ROLLER 6 O
O
O
1A05X2152A ASS'Y_SWING_SELECTOR 1 O
O
O
7805B058XA PIPE_SELECTOR_CONN 1 O
O
O
720511601A GEAR_BILL_GUIDE_P 1 O
O
O
720511900A HOPPER_GUIDE_L 1 O
O
O
720512000A HOPPER_GUIDE_R 1 O
O
O
720508501A IR_GUIDE 1 O
O
O
720512201A LINK_SELECTOR 1 O
O
O
1A05X3129A LCD(ODT_TECH 128X80) (W/ 2P Harness) 1 O
O
O
8605A009XA COOLING_FAN_40X40(t=10mm) (W/ SHP-24 Harness) 1 O
O
O
1A05X1082A SMPS_P 1 O
O
O
8805A036XA FLIM_SMPS_P 1 O
O
O
8600B002XA SOLENOID (KHA38H06A) (W/ SHP-19 Harness) 1 O
O
O
8600A003XA MOTOR_STACKER (W/ SHP-18 Harness) 1 O
O
O
1A05X1092A P-POWER_IO V1.5 1 O
O
O
1A05X1069A P-AMP V1.3 1 O
O
X
1A00X1003A PBA_ENCODER_1 (W/ SHP-27 Harness) 1 O
O
O
1A00X1003A PBA_ENCODER_2 (W/ SHP-01 Harness + 2 PBA) 1 O
O
O
1A00X1004A PBA_HOPPER_1 (W/ SHP-22 Harness) 1 O
O
O
1A00X1004A PBA_HOPPER_2 (W/ SHP-10 Harness + 2 PBA) 1 O
O
O
