16
©
Scania CV AB 1997 01:01-02
Program 96
Cylinder head
Checking and machining the sealing surface
against cylinder block.
Cylinder head is checked for cracks and other
defects. The sealing surface against the cylinder
block is checked against a surface plate. If the seal-
ing surface must be machined, cylinder head height
after machining must not be less than 114.4 mm.
After machine flat, new sealing grooves for the
gasket must be milled.
Use tool 587 272.
Also machine the recesses for the sealing rings.
Depth 0.9-1.1 mm.
Sealing groove in cylinder head
01:01-02
