1 Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
Note:
Read the whole text of the operating manual before as-
sembly and commissioning.
This operating manual should help you to familiarise
yourself with your product and to use it for its intended
purpose.
The operating manual includes important instructions
for the safe, proper and economic operation of the
product, for avoiding danger, for minimising repair costs
and downtimes and for increasing the reliability and ex-
tending the service life of the product.
In addition to the safety instructions in this operating
manual, you must also observe the regulations applica-
ble to the operation of the product in your country.
Keep the operating manual package with the power tool
at all times and store it in a plastic cover to protect it
from dirt and moisture. They must be read and carefully
observed by all operating personnel before starting the
work.
The product may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards.
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such products must also be observed.
We accept no liability for accidents or damage that oc-
cur due to a failure to observe this manual and the
safety instructions.
2 Product description (Fig. 1-22)
1. Steering
2. Drive bow
3. Engine brake lever
4. Upper push bar
5. Quick clamp lever
6. Plastic star grip nut
7. Cable clip
8. Lower push bar
9. Guide for push bar
10. Fuel filler cap
11. Fuel tank
12. Air filter cover
12a. Air filter
13. -
14. Water connection
15. Idler
16. Spark plug connector
16a. Spark plug
17. Exhaust pipe
18. Oil dipstick
19. Side discharge flap
19a. Side discharge
20. Cutting height adjustment
21. Drive wheel
22. Discharge flap
23. Grass collection basket
24. Rope hook
25. Pull starter
26. Mulching insert
27. Blade
28. Blade screw
29. Washer
30. Engine spindle
31. Carburettor screw
32. V-belt
3 Scope of delivery (Fig.1-2)
Item Quanti-
ty
Designation
4. 1 x Petrol lawnmower with upper push bar
5. 2 x Quick clamp lever
6. 4 x Plastic star grip nut
7. 1 x Cable clip
8. 1 x Lower push bar
9. 2 x Guide for push bar
19a. 1 x Side discharge
23. 1 x Grass collection basket
26. 1 x Mulching insert
A 2 x Screw M8
B 2 x Washer, small
C 2 x Washer, large
D 2 x Plastic disc
1 x Operating manual
4 Proper use
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance
of the safety instructions, as well as the assembly in-
structions and operating information in the operating
manual.
30 | GB www.scheppach.com
