Assembly
28 210.00 | PZN-plus | Assembly and Operating Manual | en | 389374
Size l1* [mm]
100 IS 49.9
100-KVZ 59.8
100 AS-KVZ 79.8
100 IS-KVZ 79.8
125 32.5
125 AS 56.9
125 IS 56.9
125-KVZ 67.5
125 AS-KVZ 92.0
125 IS-KVZ 92.0
160 42
160 AS 71.5
160 IS 72.5
160-KVZ 82
160 AS-KVZ 111.5
160 IS-KVZ 112.5
Tab.: Setting dimensions
NOTE
The magnetic switch MMS 22-PI1 can be adjusted and taught in
two ways.
l
"Standard mode" allows for quick installation on the T-nut
preset by SCHUNK in the groove or the defined setting
dimension "l1."
l
In "Optimal Mode", the sensor identifies the optimal position
in the groove itself.
SCHUNK recommends "Optimal Mode" for setting the sensors.
Further information on the installation of the
sensor, }5.3.9 [/35]
5.3.3 Switch-off hysteresis for magnetic switches
Sensors MMS 22, MMS 22-PI1, MMS 22-PI2 and MMS-P 22
The smallest detectable difference in stroke is defined in the
following table:
For products with X mm
nominal stroke per jaw
Min. query range per jaw/
min. queried stroke difference per jaw
X ≤ 5 mm 30 % of the nominal stroke per jaw
X > 5 mm to X ≤ 10 mm 20 % of the nominal stroke per jaw
