SCHUNK PLZ Plus Series User Manual

Maintenance
62 210.00 | PZN-plus | Assembly and Operating Manual | en | 389374
with gripping force
maintenance I.D.
gripping
Size Pre-tension distance
[mm]
Spring force [N]
40 10 111
50 14 183
64 46 388
80 36 701
100 46 1389
125 71 2037
160 96 3927
200 100 7373
240 48 6267
300 100 13464
380 63 14163
7.5 Drawings
The following figures are example images.
They serve for illustration and assignment of the spare parts.
Variations are possible depending on size and variant.
