Maintenance
210.00 | PZN-plus | Assembly and Operating Manual | en | 389374 65
7.5.3 Variant with force amplification cylinder
1* Wearing part, replace during maintenance.
Included in the seal kit. Seal kit can only be ordered
completely.
2* not for PZN-plus 64 - 125
3* from size PZN-plus 125
4* from size PZN-plus 160
