Assembly
38 210.00 | PZN-plus | Assembly and Operating Manual | en | 389374
Size l1* [mm]
160-1 40.5
160-1-AS 71.75
160-1-IS 71.0
160-1-KVZ 80.5
160-1-AS-KVZ 111.75
160-1-IS-KVZ 111.0
Tab.: Setting dimensions
* Setting dimension l1, from product bottom edge to front sensor
Sizes 64, 80, 100, 125, 160
1. Turn the sensor (1) into the groove (2).
OR: Slide the sensor (1) into the groove (2) until the sensor (1)
stops at the T-nut (3).
2. Secure the sensor (1) using the set-screw (4).
Tightening torque: 10Ncm
3. Adjust sensor (1), see sensor assembly and operating manual.
1. Turn the sensor (1) into the groove (2).
OR: Slide the sensor (1) into the groove (2) until the sensor (1)
stops at the T-nut (3).
2. Secure the sensor (1) using the set-screw (4).
Tightening torque: 10Ncm
3. Adjust sensor (1), see sensor assembly and operating manual.
Size 80-AS
During the monitoring process, the first and last 15% of the
nominal stroke will not produce a change in the analog signal. It
is therefore not possible to monitor the end positions. If you
have questions, please contact SCHUNK.
Size Stroke 1 Stroke 2
100 % 15 % 100 % 15 %
PZN-plus
80-AS
8 mm 1.2 mm 4 mm 0.6 mm
