SCHUNK SRU Series User Manual

Technical data
20
10.00 | SRU | Assembly and Operating Manual | en | 389439
3.2 Basic data
Operating data
Designation
SRU 8, 10, 12, 14
S/H/W
Angle of rotation [°] 180
End position adjustability [°]
Min.
Max.
-3
+90
Repeatability [mm] < 0.07
Pressure medium Compressed air, compressed air
quality according to
ISO 8573-1: 7:4:4
Nominal operating pressure
[bar]
6
Min. pressure [bar] 4.5
Max. pressure [bar] 8
More technical data is included in the catalog data sheet.
Whichever is the latest version.
Ambient conditions and operating conditions
Designation
SRU 8, 10, 12,
14
variant S/H
SRU 8, 10, 12,
14
variant W
Ambient temperature [°C]
min.
max.
+5
+60
+5
+90
Relative air humidity [%]
min.
max. (free from condensation)
35
85
IP protection class * 65
Noise emission [dB(A)] ≤ 70
* For use in dirty ambient conditions (e.g. sprayed water, vapors,
abrasion or processing dust) SCHUNK offers corresponding
product options as standard. SCHUNK also offers customized
solutions for special applications in dirty ambient conditions.
