Maintenance
10.00 | SRU | Assembly and Operating Manual | en | 389439
41
8.4.2 Notes for assembly
Assembly takes place in the opposite order to disassembly.
Observe the following:
• Unless otherwise specified, secure all screws and nuts with
Loctite no. 243 and tighten with the appropriate tightening
torque.Tightening torque for screws [
}
41]
NOTICE
Material damage due to incorrect assembly!
The O-rings (42) can become damaged during assembly.
• Install the cover for the internal air feed-through (18)
carefully.
• The cover for the internal air feed-through (18) can be
installed rotated by 180°, if required.
8.4.3 Tightening torque for screws
Position of the item numbers Assembly drawing [
}
42]
Specified in Nm
Item SRU
8 10 12 14
34 0.75 0.75 1.3 1.3
41 0.75 0.75 1.3 1.3
60 0.75 0.75 1.3 1.3
