Assembly
10.00 | SRU | Assembly and Operating Manual | en | 389439
23
Ø Screw the product to the machine/system, Mechanical
connection [
}
24].
✓ Use centering sleeves.
✓ Observe the tightening torque for the mounting screws, see
the following table.
Ø Fasten attachment with two cylindrical pins and two fastening
screws to the pinion, Mechanical connection [
}
24].
NOTICE!Insert the cylindrical pins by hand. Do not hammer
the pinion.
Ø In the main air connections "A" and "B", screw in throttle valves
and connect compressed air lines, Pneumatic connection
[
}
26].
OR with hose-free direct connection:
✓ Mount throttle valves in the supply lines "a" and "b".
✓ Use O-rings from the accessory pack.
Ø Check that all of the throttle valves are closed.
Ø Screw in locking screws in open and not required air
connections where appropriate.
Ø Adjust end positions, Adjustment of the end positions [
}
27].
Ø Adjust center position if necessary, Adjustment of the central
position (Variant M) [
}
28]
Ø Mount sensor if necessary, Installing the sensors [
}
29].
Ø Adjust swiveling speed, Setting the speed [
}
32].
Ø Adjust shock absorber stroke, Adjustment of the shock absorber
stroke [
}
34].
