10.00 | SRU | Assembly and Operating Manual | en | 389439
5 Assembly
5.1 Assembling and connecting
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
• Before starting any work on the product: Switch off the power
supply and secure against restarting.
• Make sure, that no residual energy remains in the system.
NOTICE
Material damage due to faulty settings and assembly.
If the end position is approached too aprubtly, the product may
be damaged.
• Ensure the turning / swiveling movement is carried out
without bouncing or bumping.
• Therefore provide sufficient throttling and damping.
• Please observe the information in the catalog data sheet.
NOTICE
Risk of damage to the product!
If during first actuation the exhaust throttle valves are open, the
product may move in an uncontrolled manner.
• Before actuation, check that the exhaust throttle valves are
closed and if necessary close any open ones completely.
NOTE
• Observe the requirements for the compressed air supply,
Technical data [
}
19].
• In case of compressed air loss (cutting off the energy line), the
product loses its dynamic effects and does not remain in a
secure position. However, the use of a SDV-P pressure
maintenance valve is recommended in this case in order to
maintain the dynamic effect for some time.
