SCHUNK STM 48V - Type Key and Nameplate

Description of the module
05/STM-48V/en/2011-04-01/CW 19
5.1.4 Type key and nameplate
Order designation
STMxxx - xxx - S - x - xx
Type
STM210 = d 210 mm
STM170 = d 170 mm
STM135 = d 135 mm
voltage
048 = 48 V rated motor voltage
cable version
S = with plug connection for power component and en-
coder cable
brake
N = without brake
B = with brake
IP protection class
40 = IP40 protection class
The nameplate is attached to one of the broad sides of the mod-
ule.
Designation
Specification
manufacturer
SCHUNK GmbH & Co. KG
type / model - protection class
STM210-48-S-N-40
ID
03068xx
rated torque (M
N
)
10 Nm
voltage (U
N
)
48 V
current (I
N
)
7 A
Table 5 Data on the nameplate (example STM210)
