SCHUNK STM 48V - Technical Data STM170

Technical Data
05/STM-48V/en/2011-04-01/CW 21
Type
STM135 48V
temperature sensor (type)
KTY84
max. permissible operating temperature [°C (°F)]
+85 (+185)
insulation class
class F DIN 57530
output shaft power P
n
[kw]
0,08
intermediate circuit voltage U
ZK
[V]
48
rated torque M
n
[Nm]
2,5
rated current I
n
[A]
4,16
peak current I
max
[A]
12,98
torque constant K [Nm/A]
0,6
rated speed n
n
[rpm]
300
max. speed n
max
[rpm]
500
winding resistance (phase-phase) R
20
[Ohm]
3,2
winding inductivity (phase-phase) L
20
[mH]
4,77
electrical time constant T [ms]
1,49
numbers of pole pairings N
15
Specifications for the integrated measuring system
type
5V TTL-Signal (Incremental), magnetic measuring
system with reference track
power supply [V]
5 ± 10 %
mean current input [mA]
65
pulse number per revolution [pulses/rev.]
18432 (on quadruple evaluation)
absolute resolution of the sensor [°]
0,020
Table 6
6.1.2 Technical Data STM170
Note
All the technical data shown in the chart refer to the indicated
heat conducting surface.
Type
STM170 48V
ID
03068xx
Heat conducting surface [mm²]
49302
Mechanical operating data
deadweight [kg]
4,7
dimension (Ø x L) [mm]
170 x 66
center bore (Ø) [mm]
32
ambient temperature [°C (°F)]
Min.
+5 (+41)
