SCHUNK STM 48V - 6 Technical Data; Technical Data des STM; Technical Data STM135

Technical Data
20 05/STM-48V/en/2011-04-01/CW
6 Technical Data
6.1 Technical Data des STM
Further technical data can be found in our catalog. The most re-
cent version applies.
6.1.1 Technical Data STM135
Note
All the technical data shown in the chart refer to the indicated
heat conducting surface.
Type
STM135 48V
ID
03068xx
Heat conducting surface [mm²]
57686
Mechanical operating data
deadweight [kg]
2,7
dimension (Ø x L) [mm]
135x 63
center bore (Ø) [mm]
15
ambient temperature [°C (°F)]
Min.
+5 (+41)
Max.
+55 (+131)
mass moment of inertia of rotating parts [kg m²]
0,001431
max. mass moment of inertia [kg m²]
0,05
rotation range [°]
>360 (turning endlessly)
positioning accuracy *
1
[°]
0,02
*
1
Distribution of the end positions of 100 successive motions. When approaching from the same direction.
measuring system
Incremental
IP rating
40
permissible operating mode
S1 - continuous operation*
2
*
2
Applies only if the preconditions in chapter 7.1, page 27 are fulfilled. Otherwise, S6 - continuous mode with intermittent load is
the permitted operating mode.
Electrical connection - required cable cross-sections and number of wire strands
power [mm²]
3 x 1
grounding [mm²]
1 x 1
shaft encoder [mm²]
8 x 0,25
temperature sensor [mm²]
2 x 0,25
specifications for the integrated motor
motor type
synchronous
switching
star
