Assembly
05/STM-48V/en/2011-04-01/CW 29
Note
All dimensions of the drawings can be taken from our internet site
under "CAD data service".
1 - Fastening screws M10 3 - Centering pin D5/H7
2 - Centering pin D12/H7 4 - Fastening screws M12
Figure 6 View of the assembly of the adapter plates on rotor and
basic carrier
