46
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
23B. BURNER & TUBE KIT ASSEMBLY CHART MODELS S100U / ITBU
MODELS S100U & ITBU are approved for indoor commercial / industrial non-residential appli-
cations. For outdoor, wet and harsh environment applications refer to models SPW-JZ / IWP
(powder coated burner box) and/or STW-JZ / IW (stainless steel burner box).
BEFORE INSTALLING: ENSURE you have the CORRECT TUBE KIT(s) for the
BURNER INPUT
S100U / ITBU - TUBE KIT PART # & QUANTITY REQUIRE
D
2ndary
Tube Kit Gross Weight (lbs) ->
100 145 170 170 170
65
Side-by-Side Tubes Length ->
10' 15' 20' 20' 20'
10'
TM-1410-
SU
TM-1415-
SU
TM-1020-
SU
TM-0020-
SU
TM-A120-
SU
TM-0010-
SU
2 x 10'
1
2 x 10'
1
2 x 15'
1
2 x 15'
1
2 x 20'
1
2 x 15'
1
2 x 20'
1
2 x 20'
1
2 x 30'
1+ 1
2 x 30'
1+ 1
2 x 30'
1+ 1
** These kits include Turn Box JS-0513-BU
packed and shipped in a separate carton
*NOTE: S100U / ITBU series tubes are NOT emissive coated
Stand-Alone tube kits require no additional tube kits.
Primary tube kits require at least one additional Secondary tube kit.
Secondary tube kit require a Primary tube kit.
200,000
155,000
175,000
110,000
130,000
60,000
80,000
Stand-Alone ** Primary **
INPUT Btuh
USA - Stainless Steel Flexible Gas Connector
130,000 or less:
JL-0771-XX - 1/2”x24”
155,000 or more:
JL-0771-YY - 3/4”x36”
FLEXIBLE GAS CONNECTOR (Included in Burner Kit) - MUST INSTALL - see Section 13
CANADA - Type 1 Hose Gas Connector
130,000 or less:
JL-0771-RC - 1/2”x30”
155,000 or more:
JL-0771-RB - 3/4”x30”
