57
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
# PART DESCRIPTION
PART #
PART DESCRIPTION PRIMARY SUPPLEMENT
7
EQUALIZER PLATE (continued)
JS-0593-NG
Outlet equalizer plate 45 NG - 25 Holes 45-NG
JS-0593-XX
Outlet equalizer plate 60 to 155 LP 60 - 155 LP
JS-0593-XY
Outlet equalizer plate 175-S LP 175 LP
JS-0593-XX
Outlet equalizer plate 60 to 200 NG 60 - 200
7A
BURNER AIR RESTRICTOR
JS-0592-AR
Burner air restrictor (45 Only) 45
JS-0591-XY
Burner air restrictor (175-S) 175 LP
8
BLOWER GASKET
JS-0578-XX
Outlet blower gasket each
9
AIR INLET C/W SCREEN
JS-0595-AC
45 NG blower ring c/w 1/2" bird screen 45 NG
JS-0594-ET
45 LP, 60 blower ring c/w 1/2" bird screen 45 LP, 60
JS-0595-EP
80, 100NG blower ring c/w 1/2" bird screen 80, 100NG
JS-0595-EA
110-200 blower ring c/w 1/2" bird screen 110-200
10
BLOWER
JS-0579-AA
Blower assembly tube burner
11
MANIFOLD BUSHING
JM-0589-XX
Manifold bushing
12
90 DEGREE ELBOW FITTING 1/2"
JS-0588-XX
Street elbow fitting 90 deg
13
GAS VALVE
JL-0701-AA
Valve gas comb 3.5" WC 24VAC VR8 NG
JL-0703-AA
Valve gas comb 10" WC 24VAC VR8 LP
JA-0506-XX
Gas Valve - Slow Open 3.5" WC NG 175, 200 NG
JA-0507-XX
Gas Valve - Slow Open 10" WC LP 175, 200 LP
14
4" NIPPLE
JS-0590-XX
Nipple 4"
15
TERMINAL BLOCK
JM-0455-DD
Terminal block
16
STEP DOWN TRANSFORMER
JA-0775-XX
Transformer 120/24V, 20VA AT120B1028
17
COMPONENT PLATE
JS-0581-XX
Component mounting plate SE
18
COMBUSTION AIR PROVING SWITCH
JS-0576-XX
Air proving switch 0.48" WC 80
JS-0576-YY
Air proving switch 0.30" WC 60
JS-0575-YY
Air proving switch 0.65" WC 110-130, 155,000
JS-0576-AA
Air proving switch 0.85" WC 45,100,175 NG
JS-0576-UG
Air proving switch 1.00" WC Model 155-A 150,000 Input
JS-0575-ZD
Air proving switch 1.10" WC 175 LP
JS-0576-XY
Air proving switch 1.15" WC 175-S 175-S LP
JS-0576-ZA
Air proving switch 1.40" WC 200-S 200-S NG & LP
19
BLOCKED FLUE PROVING SWITCH
JS-0577-ZZ
Blocked flue switch 1.41" WC
100, 175NG, 200NG
JS-0577-XY
Blocked flue switch 1.20" WC 175-S 175-S LP
JS-0577-UW
Blocked flue switch 1.33" WC 200-S LP
JS-0577-SS
Blocked flue switch 0.58" WC 60
JS-0577-YY
Blocked flue switch 0.90" WC 45, 80-155
22
EYE BOLT
JF-1012-EB
Eye Bolt
Burners with
FENWAL IGNITION CONTROL - Models: S100-F; ITB-F
20
FENWAL DSI CONTROL
JA-0567-XX
3-Trial 24Vac with blower relay “-F” Models
REPLACEMENT KIT: FENWAL CONTROL
JA-0568-KT
Fenwal Control + Wire Harness + Cable + Igniter: Replaces Fenwal & S87J
21
IGNITION CABLE
JS-0518-SA
Hi voltage wire (24") STW - 2 x 1/4" Spades
Burners with
HONEYWELL S87-J IGNITION CONTROL - Models: S100/ITB; “-H”; “-HA”; “-HS”
20
HONEYWELL IGNITION CONTROL
JA-0568-XX DISCONTINUED - NO LONGER AVAILABLE
REPLACEMENT KIT: WITH FENWAL DSI
JA-0568-KT
21
IGNITION CABLE HONEYWELL S87J
JS-0518-XX
Wire hi voltage (24") S87J Bullet Connection
Burners with CHANNEL GASLITER MICRO 50N IGNITION CONTROL - Models: S100-C; ITB-C
20
CHANNEL MICRO 50N IGNITION CONTROL
JB-0568-AA
3 Try Potted MICRO 50N DSI - Replaces existing MICRO 50N Control
Wiring Harness (not shown)
JB-0568-WH-
Wiring Harness for connection of MICRO 50N
21
IGNITION CABLE
JS-0518-SA
Hi voltage wire (24") STW - 2 x 1/4" Spades
Fenwal Control + Wire Harness + Cable + Igniter: REPLACES S87J
To Next Page
