Scotchman 9012-24M - Machine Operation; Punch Station Operation

Page 24
6.0 MACHINE OPERATION
6.1 PUNCH OPERATION
WHEN USING A URETHANE STRIPPER, SEE SECTION 7.13 FOR INSTRUCTIONS.

ALWAYS WEAR SAFETY GLASSES.

THE FIRST AND MOST IMPORTANT PROCEDURE IS THE PROPER METHOD OF
CHANGING AND ALIGNING PUNCHES AND DIES.
FIGURE 8
