7.6 ANGLE IRON BRAKE
This brake is designed to form box frames out of angle iron. It has a maximum capacity of 1/4" (6mm).
7.6A ANGLE IRON BRAKE INSTALLATION
SEE FIGURE 20 ON THE FOLLOWING PAGE.
This brake mounts in the punch station and the selector switch must be in the PUNCH position to
operate this tool. The die holder, punch retaining nut and the stripper must be removed to install this
tool. Mount the tool so that it lines up directly under the punch ram (A) and anchor it to the punch bed
with the clamps (B) provided.
7.6B ANGLE IRON BRAKE OPERATION
The down stroke of the machine must be set, to prevent damage to the tool. Grease the brake guides
every two hours of operation.
ALWAYS REMOVE THIS TOOL WHEN IT IS NOT IN USE!
