Page 96
10.0 SUPPLEMENT FOR OLDER MODELS
10.1 SHEAR ARM ASSEMBLY (SERIAL #'S 21600M & PRIOR)
ITEM PART # DESCRIPTION
A 030650 Rub Block
B 030550 Shear Arm
C 080169 Brass Bushings
D 080031 24" Shear Blades
E 006250 Lower Blade Holder
F 007100 Shear Table
G 010182 Main Pin Bushing
H 030555 Shear Arm Pin
I 080174 Grease Bolt
J 012121 Pressure Plate
K 037273 Brass Plate (2 Required)
L 218120 M-12 Set Screw
M 210014 M-12 Jam Nut
N 230207 M-10 FSHCS
O 221417 M-16 SHCS
P 205425 M-12 HHCS
Q 221322 M-12 SHCS
R 080310 Shear Slug Chute
S 030660 Tooling Slug Chute
T 204222 M-10 HHCS
U 218112 M-12 Set Screw
V 006015 Shear Arm Rub Plate
W 201432 M-12 x 80 HHCS
X 218122 M-12 x 60 Set Screw
Y 210014 M-12 Jam Nut
Z 013289 Rear Shear Guard-Metal
AA 224005 M-6 x 12 WLCS
