Page 58
7.12 OPTIONAL GAUGING EQUIPMENT AND CONTROLS
7.12A 48 INCH DELUXE BACK GAUGE
The 48 inch back gauge mounts on the drop-off side of the machine and will reach all three stations from
one point. It is designed to be used as a length stop in the shear, punch and tooling stations. It is available
with a scale, a digital readout or an electrically controlled stop. For parts identification, SEE THE
TOOLING PARTS MANUAL.
