Scotchman 9012-24M - Hold down Assembly

Page 84
9.7 HOLD DOWN ASSEMBLY
ITEM PART # DESCRIPTION
A 013185 Guard
B 080342 Housing
C 080337 Post-Left
D 080336 Post-Right
E 017340 Key 7 x 7 x 24
F 080347 Gear-Left
G 003105 Warning Label
H 080348 Gear-Center
I 080349 Gear-Right
J 080338 Wheel Shaft
K 080344 Base
L 201110 M-6 x 12 HHCS
M 141415 1/4 x 1-3/4 Roll Pin
N 017342 Hold-Down Crank (Includes 2 each O, P & Q)
O 210014 M-12 Jam Nut
P 017347 Handle
Q 221335 M-12 x 80 SHCS
R 221120 M-8 x 25 SHCS
S 080339 Wheel Washer
T 221320 M-12 x 50 SHCS
U 212014 M-12 Lock Washer
017341 Complete Hold Down
