Scotchman 9012-24M - 9012 Ironworker Parts Lists; Shear Arm Assembly Parts List

Page 72
9.0 9012 IRONWORKER PARTS LISTS
FOR YOUR CONVENIENCE, ALWAYS GIVE YOUR COMPLETE SERIAL NUMBER
WHEN ORDERING PARTS.
9.1 SHEAR ARM ASSEMBLY (SER. # 21601M & UP)
ITEM PART # DESCRIPTION
A 030650 Rub Block
B 030550 Shear Arm (Includes C & G)
C 080169 Brass Bushings
D 080031 Upper Shear Blade
E 210014 M-12 Jam Nut
F 080435 Shear Table
G 010182 Main Pin Bushing
H 030556 Shear Arm Pin
I 080174 Grease Bolt
J 012121 Pressure Plate
K 037273 Brass Plate (2 Required)
L 218120 M-12 Set Screw
M 214014 M-12 Washer
N 212014 M-12 Lock Washer
O 218120 M-12 Set Screw
P 205422 M-12 HHCS
Q 221322 M-12 SHCS
R 080428 Shear Slug Chute
S 030660 Tooling Slug Chute
T 201220 M-10 HHCS
U 218112 M-12 Set Screw
V 006015 Shear Arm Rub Plate
W 205425 M-12 HHCS
X 013289 Rear Shear Door
Y 224005 M-6 x 12 WLCS
Z 033175 Lower Blade
AA-FF: SEE THE TOOLING MANUAL.
