9.2 PUNCH ASSEMBLY
PART # DESCRIPTION
A 030640 Punch Bolster (Ser.# 21600 & Prior)
A1 080424 Punch Bolster (Ser.# 21601M & Up)
B 221420 M-16 SHCS
C 113017 Reid Washer
D 201625 M-16 HHCS
E 006013 Die Holder
F 218058 M-10 Set Screw
G 006202 #82 Die Insert (2 Inch)
H 204220 M-10 x 30 HHCS
I 026713 Punch Table (See Tooling Manual)
J 230207 M-10 x 20 FSHCS
K 016095 #40 Punch Retaining Nut
K1 016096 #45 Punch Retaining Nut
L 221315 M-12 SHCS
M&W 010236 Punch Ram & Bushing
N 036167 Lower Punch Pin
O 016620 2" Snap Ring
P 016625 2-1/2" Snap Ring
Q 032074 Upper Punch Pin & Bushing (Inc. P & U)
R 210014 M-12 Hex Nut
S & T 030619 Punch Link Set (Includes CC & DD)
U 243101 Grease Zerk
V 201440 M-12 Hex Bolt
W&M 010236 Punch Ram & Bushing
X 030657 Punch Shroud
Z 224205 M-10 x 16 WLCS
AA 077145 Hardened Pin
BB 004123 1/4" Key
CC 080192 2-1/2” Brass Spacer
DD 015131 2” Brass Spacers
EE 012078 3” Punch Holder (Includes GG)
FF 221120 M-8 x 25 SHCS
GG 015033 Punch Ram Insert (Includes BB & HH)
HH 141010 3/16 x 1/2 Roll Pin
I I 219060 M-10 x 50 Set Screw
J J 026618 Tee Nut
KK 026697 Guide Finished
LL 214012 M10 Regular Washer
MM 080063 XRS/JIG HANDLE
ITEM
Page 74
