SDMO MICS Telys - Environment, Standards, and Connectivity

10/01 5
_________________________________________________________________________________________________________________________________ Technicals characteristics
1166 - OOppttiioonnss ccoonnnneecctteedd ttoo tthhee iinntteerrffaaccee
(*)indication and fault/shutdown for oil temperature, low oil level, water heater failure and alarm/warning for, oil pressure, water tempera-
ture, oil temperature, air damper control, starter 2 control.
1177 - SSoorrttiieess rreellaaiiss
 Max switching voltage: 250Vac (277Vac for *)
 Mains and Stand-by contactor control outputs: 4.9A, 1500VA breaking capacity at cosϕ=0.7
 Electro-flaps outputs: 500mA & CIC remote contact:1A
 MX coil control output (*): 4.9A (optional relay on baseplate)
1188 - TTrraannssiissttoorr oouuttppuuttss
 Protected against short-circuit
 Output for fuel solenoid/panel lighting: 700mA
 Other outputs: 300mA
1199 - HHaarrddwwaarree ccoonnffiigguurraattiioonn
 C14/C15 connector, auxiliaries voltage selection
 C7 dip-switch, RS485 terminator
 P3 dip-switch, CAN bus terminator
 Dip-switch selection for VDE option
2200 - EEnnvviirroonnmmeenntt aanndd ssttaannddaarrddss
 Operating temperature: -15°C to +60°C
 Storage temperature: -20°C to +70°C
 Resistance to shocks: IK01, vibration: to CEI68-2-6
 Salt mist resistance : 96 hours according to EN68011-2-11
 Humidity : 95 % of humidity at 45°C.
 EMC :
- Generic standards EN50081-2 and EN50082-2
- Emissions EN55011 Class A
- Immunity EN61000-4.2, EN6100-4.3, EN61000-4.4, EN61000-4.6, EN61000-4.8, ENV50201
 CE mark, UL listed, CSA certified
Option description
CB
CB12
external start-up command
x
x
auto predisposition + external command
x
x
3ph+neutral or 1ph+N mains connection
x
x
battery charger (3 possible ratings)
x
x
water heater (3 poss. depending on supply V)
x
x
hooter
x
x
RS485 for monitoring or remote
management
x
x
option 3 module / CAN bus connection
x
x
additional engine kit (9 options) (*)
x
electro-flaps (DC or AC)
x
anti-condensation heater
x
EJP (switch, adv. warning and start -up)
x
1ph or 3ph fuel pump (control & power)
x
Air cooler (low level, disconnection)
x
differential protection and MX coil contr ol
x
CIC protection with remote contact and MX
coil control
x
bulk tank fuel pump (CF80, low level,
retention bund)
x
AMPG with optional RS485
x
option 4 module / CAN bus connection
x
three-alarm (OP,WT,OT) and module 4 kit
x
French only
