SDMO MICS Telys - Inputs Menu

10/01 19
__________________________________________________________________________________________________________________________________________" Inputs " Menu

Main bboard ((CB)
Logical status display of the inputs on interface board CB, i.e. the eleven inputs described in Section "
Technical characteristies ".
Note: the eleven inputs are also available on interface boards CB12.
MAIN BOARD (CB)
Esc: Exit
123456789 10 11
0:
********* * *
1:
Input 1:
Oil Pressure
Shutdown

Option 11 ((CB1/CB12)
Logical status display of the inputs on option 1 part of interface board CB12, i.e. the four inputs des-
cribed in Section " Technical characteristies ".
Note: the four inputs are also available on interface board CB12.
OPTION 1 (CB1/CB12)
Esc: Exit
1234
0:
****
1:
Input 1:
Oil Temp. Shutdown

Option 22 ((CB12)
Logical status display of the inputs on option 2 part of interface board CB12, i.e. the twelve inputs des-
cribed in Section " Technical characteristies ".
OPTION 2 (CB12)
Esc: Exit
123456789 10 11 12
0:
********* * * *
1:
Input 1:
Diff. or C.I.C.
trip

Option 33 MModule
Logical status display of the inputs on option 3 module, i.e. the eight inputs described in Section " Tech-
nical characteristies ".
OPTION 3 MODULE
Esc: Exit
12345678
0:
1:
Input 1:
EJP J-1
********

Option 44 MModule

Option 55 MModule
Logical status display of the eight inputs on option 4 module. As these inputs can be programmed, the
wording of each input varies according to the programming performed. For that reason, the wording
does not appear on the screen opposite.
By setting parameter
901
to 1, the inputs of the option 5 module are displayed programmed with an MTU
engine.
Display of logical status of inputs of option 5 module. For the MTU engine, only inputs 1, 2, 3, 4 and 5 are
used.
By setting parameter
902
to 1, the inputs of the option 5 module are displayed, programmed with Cummins
engine QST30.
Display of logical status of inputs of option 5 module. For the QST30 engine, only inputs 1, 2 and 3 are used.
OPTION 4 MODULE
Esc: Exit
12345678
0:
********
1:
Input 1:
OPTION 5 MODULE
Esc: Exit
12345678
0:
********
Input 1:
MTU oil pressure fault
OPTION 5 MODULE
Esc: Exit
12345678
0:
********
Input 1:
QST30 overspeed fault
