SDMO MICS Telys - Frequency and Hours Counter; Currents

12 10/01
Viewing the electrical values_______________________________________________________________________________________________________________________________
44..22.. CCuurrrreennttss
To view the various AC currents, press the
I
button successively. The values are expressed in true root mean square Amps. Depending on the
client's needs (type of electrical installation), several screens are possible:
 3 phase with neutral (3ph+N)
 3 phase without neutral (3ph)
 2 phase (2ph+N)
 1 phase (1ph+N)
Note: one of the four choices above has been factory programmed as per the client's specification.

3 pphase wwith nneutral ((3ph+N)
 Press
I
to get the three phase currents:
I1
= current in phase 1
I2
= current in phase 2
I3
= current in phase 3
Phase I1
current I2
(Amps) I3
ext command=1 17:10
gen running 12/01/00
536
542
543
 Press
I
again to get the neutral current:
In
= current in the neutral
Note : the neutral current is calculated by vector summation of the three phase currents..
 Press
I
again to bring up the first screen and so on ...
Neutral
current In
(Amps)
ext command=1 17:10
gen running 12/01/00
23

3 pphase wwithout nneutral ((3ph)
 Press
I
to get the three phase currents:
I1
= current in phase 1
I2
= current in phase 2
I3
= current in phase 3
 If you press
I
again, nothing changes.
Phase I1
current I2
(Amps) I3
ext command=1 17:10
gen running 12/01/00
536
542
543
 Press
I
to get the two phase currents:
I1
= current in phase 1
I2
= current in phase 2
 If you press
I
again, nothing changes.
Phase I1
current I2
(Amps)
ext command=1 17:10
gen running 12/01/00
246
238

2 pphase ((2ph+N)

1 pphase ((1ph+N)
 Press
I
to get the 1 phase current :
I1
= 1 phase current
 If you press
I
again, nothing changes.
Phase I1
current
(Amps)
ext command=1 17:10
gen running 12/01/00
95
44..33.. FFrreeqquueennccyy aanndd hhoouurrss ccoouunntteerr
To view the generating set frequency and number of running hours, press the
F/
button. Values are expressed in Hertz (Hz) and in hours res-
pectively.
The minutes are counted from 0 to 59 minutes; on the 60th minute, the number of hours is incremen-
ted and the number of minutes goes to 0.
Example of "overview" screen showing frequency and number of generator running hours and minutes.
Note: a maximum of 32767 running hours can be displayed. The display is in whole hours.
Frequency (Hz)
No hours
ext command=1 17:10
gen running 12/01/00
5500
.
2
664433
4455
No minutes
