Option 44 MModule
Option 55 MModule
Logical status display of the ten outputs on option 4 module.
As these outputs can be programmed, the wording on each line varies according to the programming
performed. For that reason, the wording does not appear on the screen opposite.
By setting parameter
901
to 1, the inputs of the option 5 module are displayed, programmed with an MTU engine.
By setting parameter
902
to 1, the outputs of the option 5 module are displayed, programmed with Cummins engine QST30.
" Inputs " Menu__________________________________________________________________________________________________________________________________________
Option 33 MModule
Logical status display of the ten outputs on option 3 module.
As these outputs can be programmed, the wording on each line varies according to the programming
performed. For that reason, the wording does not appear on the screen opposite.
Display of logical status of outputs of option 5 module. For the MTU engine, only outputs 1, 2, 3, 4 and 5 are
used.
Display of logical status of outputs of option 5 module. For the QST30 engine, only output1 is used.
By setting parameter
903
to 1, the outputs of the option 5 module are displayed, programmed with John Deere 6081HF engine.
Display of logical status of outputs of option 5 module. For the John Deere engine, only output 9 is used.
(*) If there is a problem with current consumption, use output relay #9 as this supports more than 2.5A. The
'Diagnostic' input on the JDEC electronics card needs a more current than 1A.
By setting parameter
904
to 1, the outputs of the option 5 module are displayed, programmed with Volvo D12 engine.
Display of logical status of outputs of option 5 module. For the Volvo D12 engine, only ioutputs 1, 2, 3 and 4
are used.
