10/01 31
Example of screen showing "max. battery voltage" alarm designated
08-00
and "emergency stop" fault
designated
00-11
.
The alarms and faults are displayed in the same way as for versions 0.01B and 1.04D:
- Up to two codes (max.) displayed on screen
- Fault takes priority over alarm
- Faults are reset in order of appearance
For more details, refer to paragraph 8.
All the alarms and faults which can appear on the MICS Telys screen are listed in the table below.a.
_____________________________________________________________________________________________________Appendix - software version 1.05e: "international" language
(símbolos 3) %
(símbolos 4) RPM
(símbolos 5) Volts
00-1
08-0
24.2
50
0
Wording
Alarm
Fault
Generated on
Generator set emergency stop
impossible
00-1
CB, CB12
External emergency stop
impossible
01-1
CB, CB12
Engine oil pressure
impossible
02-1
CB, CB12
Engine water temperature
impossible
03-1
CB, CB12
Daily fuel tank leve l low
04-0
04-1
CB, CB12
Radiator water level low
impossible
05-1
CB, CB12
Alternator overload or short -circuit
06-0
06-1
CB, CB12
Engine overspeed
impossible
07-1
CB, CB12
Min. battery voltage
08-0
08-1
CB, CB12
Max. battery voltage
09-0
09-1
CB, CB12
Lithium battery absent
10-0
impossible
CB, CB12
Generator set no start
impossible
11-1
CB, CB12
Min. alternator voltage
12-0
12-1
CB, CB12
Max. alternator voltage
13-0
13-1
CB, CB12
Min. alternator frequency
14-0
14-1
CB, CB12
Max. alternator frequ ency
15-0
15-1
CB, CB12
Option 3 module CAN bus
impossible
16-1
CB, CB12
Option 4 module CAN bus
impossible
17-1
CB12
Option 5 module CAN bus
impossible
18-1
CB12
Option 6 module CAN bus
impossible
19-1
CB12
Spare
RS485 communication
21-1
impossible
CB, CB12
Hardware watchdog
impossible
22-1
CB, CB12
Spare
Spare
Normal contactor open (system side)
25-0
impossible
CB, CB12
Emergency contactor open (generating set side)
26-0
impossible
CB, CB12
Oil temperature
impossible
27-1
CB, CB12
Oil level low
impossible
28-1
CB12
No water preheating
29-0
29-1
CB12
Differential trigger
30-0
30-1
CB12
Permanent insulation monitor trigger
31-0
31-1
CB12
Differential relay connection
impossible
32-1
CB12
Permanent insulation monitor connection
impossible
33-1
CB12
Battery charger fault
34-0
34-1
CB12
Air cooler trip
impossible
35-1
CB12
Air cooler low level
impossible
36-1
CB12
Fuel pump 1 trip
37-0
37-1
CB12
Retention tank
38-0
38-1
CB12
Fuel tank low level
39-0
39-1
CB12
Water flow
impossible
40-1
module 3
Fire detection
impossible
41-1
module 3
Oil leak
impossible
42-1
module 3
Fuel leak
impossible
43-1
module 3
Air cooler compartment door open
impossible
44-1
module 3
MCPS door open
impossible
45-1
module 3
Main circuit breaker open
46-0
46-1
module 3
Overload
47-0
impossible
CB12
