Section 4: Deploying and Operating SBE 19plus V2
63
OutputFormat=2 (raw frequencies and voltages in decimal)
Data is output in the order listed, with a comma followed by a space between
each parameter. Shown with each parameter are the number of digits and the
placement of the decimal point. Leading zeros are suppressed, except for one
zero to the left of the decimal point.
1. Temperature
A/D counts = tttttt
2. Conductivity
conductivity frequency (Hz) = cccc.ccc
3. Strain-gauge pressure (if PType=1)
A/D counts = pppppp
4. Strain-gauge pressure sensor temperature compensation (if PType=1)
pressure temperature compensation voltage = v.vvvv
5. Quartz pressure sensor pressure (if PType=3)
Quartz pressure frequency (Hz) = ppppp.ppp
6. Quartz pressure sensor temperature compensation (if PType=3)
Quartz temperature compensation voltage = v.vvvv
7. External voltage 0 (if Volt0=Y)
external voltage 0= v.vvvv
8. External voltage 1 (if Volt1=Y)
external voltage 1 = v.vvvv
9. External voltage 2 (if Volt2=Y)
external voltage 2 = v.vvvv
10. External voltage 3 (if Volt3=Y)
external voltage 3 = v.vvvv
11. External voltage 4 (if Volt4=Y)
external voltage 4 = v.vvvv
12. External voltage 5 (if Volt5=Y)
external voltage 5 = v.vvvv
13. SBE 38 secondary temperature (if SBE38=Y)
SBE 38 temperature (°C, ITS-90) = ttt.tttt
14. GTD #1 pressure (if GTD=Y or DualGTD=Y)
GTD #1 pressure (millibars) = ppppppppp / 100,000
15. GTD #1 temperature (if GTD=Y or DualGTD=Y)
GTD #1 temperature (°
C, ITS-90) = tt.ttt
16. GTD #2 pressure (if DualGTD=Y)
GTD #2 pressure (millibars) = ppppppppp / 100,000
17. GTD #2 temperature (if DualGTD=Y)
GTD #2 temperature (°C, ITS-90) = tt.ttt
18. Time (Moored mode [MM] only)
date, time = dd Mmm yyyy, hh:mm:ss
(day month year hour:minute:second)
Example: Profiling mode, strain-gauge pressure sensor, 2 external voltages sampled,
example scan = tttttt, cccc.ccc, pppppp, v.vvvv, v.vvvv, v.vvvv
= 676721, 7111.133, 791745, 2.4514, 0.0590, 0.1089
• Temperature = tttttt = 676721;
temperature A/D counts = 676721
• Conductivity = cccc.ccc = 7111.133;
conductivity frequency = 7111.133 Hz
• Pressure = pppppp = 791745;
Pressure A/D counts = 791745
• Pressure sensor temperature compensation = v.vvvv = 2.4514;
Pressure temperature = 2.4514 volts
• First external voltage = v.vvvv = 0.0590;
voltage = 0.0590 volts
• Second external voltage = v.vvvv = 0.1089;
voltage = 0.1089 volts
Note:
Although OutputFormat=2 outputs
raw data for temperature,
conductivity, etc., it outputs
engineering units for SBE 38 and
GTD data.
