CONTROLS/INSTRUMENTS/EQUIPMENTS
Information Display
smo2008-001-033_a
TYPICAL
1. Information display
Compass
RXP-X 255 Model
Displays the cardinal points to indicate
the orientation of the watercraft.
smo2008-001-024_a
TYPICAL
1. Compass
WARNING
Use the compass as a guide only.
Nottobeusedforprecisionnavi-
gation purposes.
Hourmeter (HR)
Displays the time in hours of the water-
craft usage.
smo2008-001-025_a
TYPICAL
1. Hourmeter
Message Display
Displays messages from the monitor-
ing system.
Refer to
TROUBLESHOOTING
section
for more details.
smo2008-001-026_a
TYPICAL
1. Message display
Water Temperature
GTS Pro Models
Displays the water temperature of the
water surface in degrees Celsius (°C)
or Fahrenheit (°F).
smo2008-001-028_a
TYPICAL
1. Water temperature
Indicator Lights
The indicator lights (pilot lamps) will
inform you of a particular condition or if
an anomaly occurs.
Refer to
MONITORING SYSTEM
for
details.
Water Temperature Display
RXP-X 255 MODEL
Displays the water temperature of the
surface water in degrees Celsius (°C)
or Fahrenheit (°F).
