STORAGE AND PRESEASON PREPARATION
4. Liberally lubricate throttle body in-
side and out.
5. Clean off any lubrication on the
throttle body intake hose flange.
6. Install air intake hose to the throttle
body.
Throttle Body Lubrication
Lubricate throttle body with XPS Lube
or an equivalent.
Use fitting for that purpose provided in
the engine compartment.
With the engine not running, make
sure to spray lubricant at least 3 to 5
seconds for proper lubrication.
smo2008-001-051_a
MODELS WITHOUT AN ENGINE COVER
1. Fitting
smo2008-001-052_a
MODELS WITH AN ENGINE COVER
1. Fitting
Exhaust System Protection
In areas where temperature may
freeze, water trapped in the exhaust
system and intercooler must be re-
moved.
Using the flushing connector on jet
pump support, inject pressurized air
(around 379 kPa (55 PSI)) into system
until there is no more water flowing
from jet pump.
smo2008-001-054_a
1. Flushing connector — location may differ
The following hosecanbefabricated to
ease draining procedure.
smo2008-001-053_a
TYPICAL
1. Flushing connector adapter
2. Hose 12.7 mm (1/2 in)
3. Air hose male adapter
NOTICE
Failure to drain the ex-
haust system may cause severe
damage to the intercooler (super-
charged models) and exhaust mani-
fold.
Remove special tools.
Engine Internal Lubrication
Remove engine cover (as applicable).
Remove ignition coils, refer to
MAI
N-
TENANCE PROCEDURES
.
_______________
79
