SPECIFICATIONS
WATERCRAFT GTS PRO
ENGINE
Rotax
®
1503 4-TEC
®
.
Single Over Head Camshaft (SOHC)
Type
96 kW
Number of cylinders 3
Number of valves
12 valves (4 per cylinder) with
hydraulic lifters (no adjustment)
Displacement 1 494 cm³ (91.2 in³)
Type Naturally aspirated
Intake system
Throttle body 52 mm (2 in)
Bore 100mm(3.9in)
Stroke
63.4 mm (2.5 in)
Compression ratio
10.6:1
Cooling Closed-loop system
ELECTRICAL SYSTEM
Ignition Digital inductive
Starter
Electric
Battery 12 V, 30 A•h. Electrolyte type
Make and
type
NGK, DCPR8E
Spark plug
Gap
0.75 mm (.03 in)
PROPULSION
Propulsion system
Sea-Doo
®
direct drive
Type
Axial flow, single stage. Large
hub with 10-vane stator
Jet pump
Material
Composite/aluminum
Impeller
Stainless steel
Transmission
Direct drive,
forward/neutral/reverse
88
