4.7. ACU Factory Default Parameter Settings – Series 97B & 00B Antennas
The following table shows the factory default parameters for the ACU interfaced to a Series 97B/00B Antenna. You
may need to optimize some of these parameters. Refer to the individual parameter setting information in the Setup
section of your ACU manual.
PARAMETER C-Band
DishScan®
Ku-Band
DishScan®
My Parameters
EL TRIM 0
AZ TRIM 0
AUTO THRES 100
EL STEP SIZE 0
AZ STEP SIZE 0
STEP INTEGRAL 0
SEARCH INC 10 5
SEARCH LIMIT 200 100
SEARCH DELAY 30
SWEEP INC 0040
SYSTEM TYPE 0005 *
GYRO TYPE 2
POL TYPE 72
POL OFFSET 30
POL SCALE 90
AZ LIMIT 1 0
AZ LIMIT 2 0
EL LIMIT 12 90
AZ LIMIT 3 0
AZ LIMIT 4 0
EL LIMIT 34 90
AZ LIMIT 5 0
AZ LIMIT 6 0
EL LIMIT 56 90
5V OFFSET 0
5V SCALE 0
TRACK DISP Refer to TRACK DISP parameter
TX POLARITY 2
* Modem Lock input & Modem TX Mute functions are NOT set; refer to SYSTEM TYPE
parameter information.
