Sea Tel 14400MK2-21 - Drawings

SINGLE LEVEL MFG BILL OF MATERIAL
FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR
1 1 EA 135628-1 A GENERAL ASS'Y, 14400MK2-21
2 1 EA 128268-3 C ANTENNA ASS'Y, 3.6 M, DUAL C / QUAD K
4 1 EA 135631-1 A FEED ASS'Y, DUAL C, QUAD KU
5 2 EA 134164-1 A LNB, C-BAND, DRO, 8225RF
7 1 EA 132463-1 C LNBF, QUAD, KU, INVERTO, MODIFIED
20 1 EA 131057-3 C3 ENCLOSURE ASS'Y, PCU, 09G2, 3 CH, 422
21 1 EA 131227-1 C ENCLOSURE ASS'Y, MOTOR DRIVER, 09G2
22 1 EA 124039-1 D MOTOR, SIZE 34, BLDC W/ ENCODER
23 2 EA 125974-1 E3 MOTOR, SIZE 34, BLDC W/ BRAKE, 15-PIN
24 1 EA 134826-1 A HOME SWITCH ASS'Y, SHIELDED, GEN2, 97
25 1 EA 131381-1 C EXTRA LOW POWER SMART GPS SENSOR,
SER
28 1 EA 128204-1 B1 RF SWITCH ASSEMBLY
30 1 EA 129526-36 B HARNESS ASS'Y, PCU TO MOTOR DRIVER, X
31 2 EA 130082-56 A HARNESS, EL/CL MOTOR INTERFACE, 56 IN
32 1 EA 130083-64 A HARNESS ASS'Y, AZ MOTOR INTERFACE, 64
33 1 EA 130084-64 C HARNESS, HOME FLAG ADAPTER, 64 IN
34 1 EA 135633-1 A HARNESS ASS'Y, REFLECTOR, 14411
40 1 EA 115708-3 H3 CIRCUIT BREAKER BOX ASS'Y, 97 220V
41 1 EA 127940-2 B POWER RING ASS'Y, 22 IN, 96 IN. CONTA
42 1 EA 124288-72 H CABLE ASS'Y, AC POWER, 72 IN
50 1 EA 128254-18 A HARNESS ASS'Y, 6 CH, RG-6, F(M) TO F(
51 1 EA 127833-24BLU A4 CABLE ASS'Y, RG-179 COAX, F(M) TO SMA
52 1 EA 127963-60RED C CABLE ASS'Y, RG-179 COAX, F TO F(RA),
52 1 EA 127963-60WHT C CABLE ASS'Y, RG-179 COAX, F TO F(RA),
52 1 EA 127963-60GRN C CABLE ASS'Y, RG-179 COAX, F TO F(RA),
52 1 EA 128385-60BLU C CABLE ASS'Y, RG-179, COAX, SMA (RA) T
60 6 EA 109391 A ADAPTER, F(F)-F(F) (BULLET), 0.84 IN
2SHT 1 OF
SYSTEM BLOCK DIAGRAM, 14400MK2-21
PROD FAMILY
LIT
EFF. DATE
11/17/2011
DRAWING
NUMBER
135626-1
REV A
