14400MK2-21 C/Ku-Band TVRO Maintenance and Troubleshooting
6-25
6.9. Pedestal Control Unit Configuration (xx97B & xx00 MK2)
The PCU is designed to be used with a variety of antenna pedestal configurations. The configuration information that
is unique to each pedestal type is stored in a Non Volatile Random Access Memory (NVRAM) in the PCU enclosure. If
the PCU is replaced or the NVRAM in the PCU should become corrupt, the PCU must be re-configured to operate with
the pedestal it is installed on. The default configuration for the PCU is model xx97B. In this configuration the PCU will
not drive any of the three torque motors to prevent damage to the unknown pedestal.
To configure the PCU, select the REMOTE COMMAND window on the DAC-2202. Refer to the table below to key in
the appropriate value for you model antenna.
6.9.1. To configure the PCU;
2. Select the REMOTE COMMAND window on the ACU.
3. Refer to the table below to key in the appropriate value for you model antenna to enter in the next
step. EXAMPLE: For a 9497B L/S Model Antenna is system type 0209.
4. Using the LEFT/RIGHT and UP/DOWN arrow keys set the Remote Command value to "N0209"
and press ENTER. The display should now show "N0209".
5. Press ENTER several times to select REMOTE PARAMETERS. Press LEFT arrow and then ENTER
to save the system type in the PCU.
6. Press RESET and the displayed Remote Version Number should now display "9497S VER 2.0x".
6.9.2. MODEL CONFIGURATION NUMBERS
The following table shows the current mode configuration values for Series 97B/00B MK2 pedestals with 09
VER 2.03a or greater PCU software.
MODEL Configuration Number
Xx09 N 0000 Turns off all drive motors
14400S N 0208
9497S N 0209
