14400MK2-21 C/Ku-Band TVRO Model 14400MK2-21 Drawings
8-1
8. Model 14400MK2-21 Drawings
The drawings listed below are provided as apart of this manual for use as a diagnostic reference. Spare Parts kits listings are
provided as part number reference for replaceable parts and common assemblies.
8.1. Model 14400MK2-21 Specific Drawings
Drawing Title
1135627-1_A System, Model 14400MK2-21 8-3
135626-1_A System Block Diagram – Model 14400MK2-21 8-5
135628-1_A General Assembly – Model 14400MK2-21 8-8
135625_A Antenna System Schematic – Model 14400MK2-21 8-10
135633-1_A Reflector Harness 8-11
128268-1_C Antenna Assembly, 3.6M, Dual C/Quad Ku 8-13
135631-1_A Feed Assembly, Dual C/Quad Ku 8-17
135632-1_A Mounting Assembly, PCU 8-19
135630-1_A Balance Weight Kit, PCU 8-21
111849-9_U 168” Radome Assembly 8-23
115912-1_G Radome Base Frame Assembly 8-26
123381_B Installation Arrangement 8-29
8.2. Series 00 General Drawings
Drawing Title
133746_B Pedestal Schematic 8-31
131857-1_B1 Base MUX Rack Panel Assembly 8-32
