14400MK2-21 Technical Specifications 14400MK2-21 C/Ku-Band TVRO
7-6
7.9.3. AC Power Cable (Pedestal & Rf Equipment)
Voltage: 110 or 220 volts AC (220 VAC Recommended)
Pedestal Power: 100 VA MAX
RF Equipment Power: 1500 VA MAX
7.9.4. Gyro Compass Interface Cable (Customer Furnished)
Type: Multi-conductor, Shielded
Number of wires 4 Conductors for Step-By-Step Gyro, 5 Conductors for Synchro
Wire Gauge: see Multi-conductor Cables spec above
Insulation: 600 VAC
7.9.5. Fiber Optic Transmitter (CFE Optional)
Model: Ortel Model 3112A
Frequency Range: 950-2050 MHz
Noise Figure: 45 dB
Impedance: 75 ohm
Connectors:
RF Type F
Fiber FC/APC "Tight Fit”
