SINGLE LEVEL MFG BILL OF MATERIAL
FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR
1 1 EA 135628-1 A GENERAL ASS'Y, 14400MK2-21
2 1 EA 111849-9 U RADOME ASS'Y, 168 INCH, WHITE/FOAM/SI
3 1 EA 115912-1 G BASE FRAME ASS'Y, 110 IN, W/PAN ACCES
15 1 EA 125411-2 M DAC-2202, DVB RCVR, 9 WIRE IF PL C3 B1 SN DAC&BDE_Box
Pedestal_Crate
16 1 EA 131856-1 A BELOW DECK KIT, 4CH, TVRO, 400MHZ PL C3 B1 DAC&BDE_Box
Pedestal_Crate
26 1 EA 122539-1 B SHIP STOWAGE KIT, XX97
27 1 EA 114569 E BALANCE WEIGHT KIT PL C3 B2
Balance_Weight_Box
Pedestal_Crate
28 1 EA 124877-1 C DECAL KIT, XX97, SEATEL (126 IN/144 I
29 1 EA 135634-1 A CUSTOMER DOC PAK, 14400MK2-21, TVRO PL C3 B1 DAC&BDE_Box
Pedestal_Crate
1SHT 1 OF
SYSTEM, 14400MK2-21
PROD FAMILY
97 TVRO
EFF. DATE
11/17/2011
DRAWING
NUMBER
135627-1
REV A
