SINGLE LEVEL MFG BILL OF MATERIAL
FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR
1 20 IN 113343-073 C WIRE, 22G, COPPER STRAND, ORG, UL1061
1 214 IN 113343-074 C WIRE, 22G, COPPER STRAND, YEL, UL1061
1 214 IN 113343-078 C WIRE, 22G, COPPER STRAND, GRY, UL1061
1 20 IN 113343-0796 C WIRE, 22G, COPPER STRAND, WHT/BLU, UL
1 214 IN 113343-0779 C WIRE, 22G, COPPER STRAND, VIO/WHT, UL
1 214 IN 113343-071 C WIRE, 22G, COPPER STRAND, BRN, UL1061
1 214 IN 113343-072 C WIRE, 22G, COPPER STRAND, RED, UL1061
2 9 EA 112267-3 PIN, SNAP N CRIMP, DB, 24-20 AWG
3 1 EA 112570-13 G BACKSHELL, D-SUB, NICKEL PLATED, DB
4 214 IN 112942-2 B TIN COPPER BRAID, 13/64 TUBULAR
5 1 EA 110935-39 K1 CONNECTOR, D-SUB, DB-25P
6 20 IN 112942-1 TIN COPPER BRAID, 1/8 TUBULAR
9 2 EA 110927-6 CONN, 0.1 IDC, 6 POS, 22 AWG, RED
12 4.5 IN 120117-060 HEAT SHRINK, 1/4 DIA, BLK, SUMITUBE B
13 2 EA 118128-1 SCREW, CAPTIVE PANEL
14 1 EA 119748-2 A1 CABLE GROMMET, PDM INTERFACE, 0.26 ID
15 2 EA 114593-105 SCREW, SOCKET HD, 4-40 x 7/16, S.S.
16 2 EA 119961-005 NUT, HEX, SMALL PATTERN, 4-40, S.S.
17 2 EA 110234-12 E1 TERMINAL, RING INSULATED, 12-10, #6,
18 2 EA 114581-005 WASHER, LOCK, #4, S.S.
2SHT 1 OF
HARNESS ASS'Y, REFLECTOR, 14411
PROD FAMILY
COMMON
EFF. DATE
11/17/2011
DRAWING
NUMBER
135633-1
REV A
