Sea Tel 14400MK2-21 - Page 87

SINGLE LEVEL MFG BILL OF MATERIAL
FIND QTY PART NO REV DESCRIPTION REFERENCE DESIGNATOR
1 1 EA 122296 A REFLECTOR, 3.6M., FOUR PANEL PL C2 SN Base&Refl_Crate
1 1 EA 122296 A REFLECTOR, 3.6M., FOUR PANEL PL C1 SN Base&Refl_Crate
2 4 EA 115446-9 Q2 FEED STRUT ASS'Y, 65.00 IN PL C2 Base&Refl_Crate
2 4 EA 115446-9 Q2 FEED STRUT ASS'Y, 65.00 IN PL C1 Base&Refl_Crate
3 1 EA 125425-1 D1 FEED ASS'Y, DUAL C/QUAD KU, DISHSCAN PL C4 B2 SN Feed_Assy_Box
Electronic_Crate
3 1 EA 125425-1 D1 FEED ASS'Y, DUAL C/QUAD KU, DISHSCAN PL C1 B2 SN Feed_Assy_Box
Base&Refl_Crate
3 1 EA 125425-1 D1 FEED ASS'Y, DUAL C/QUAD KU, DISHSCAN PL C2 B2 SN Feed_Assy_Box
Base&Refl_Crate
3 1 EA 125425-1 D1 FEED ASS'Y, DUAL C/QUAD KU, DISHSCAN PL C2 B2 SN Feed_Assy_Box
Base&Refl_Crate
4 1 EA 123331-4 D HARNESS ASS'Y, REFLECTOR PL C4 B2 I1 w/125425-1,1
Feed_Assy_Box
Electronic_Crate
4 1 EA 123331-4 D HARNESS ASS'Y, REFLECTOR PL C2 B2 I1 w/125425-1,1
Feed_Assy_Box
Base&Refl_Crate
4 1 EA 123331-4 D HARNESS ASS'Y, REFLECTOR PL C1 B2 I1 w/125425-1,1
Feed_Assy_Box
Base&Refl_Crate
4 1 EA 123331-4 D HARNESS ASS'Y, REFLECTOR PL C2 B2 I1 w/125425-1,1
Feed_Assy_Box
Base&Refl_Crate
5 1 EA 128254-18 A HARNESS ASS'Y, 6 CH, RG-6, F(M) TO F( PL C4 B2 I1 w/125425-1,2
Feed_Assy_Box
Electronic_Crate
5 1 EA 128254-18 A HARNESS ASS'Y, 6 CH, RG-6, F(M) TO F( PL C2 B2 I1 w/125425-1,2
Feed_Assy_Box
Base&Refl_Crate
2SHT 1 OF
ANTENNA ASS'Y, 3.6 METER, DUAL C / QUAD KU
PROD FAMILY
COMMON
EFF. DATE
11/18/2011
DRAWING
NUMBER
128268-1
REV C
