Basic Setup of the ACU ST94-21 C/Ku-Band TVRO
4-2
4.4. ACU Factory Default Parameter Settings – STxxx-21 Series Antennas
The following table shows the factory default parameters for the ACU interfaced to a ST-21 Series Antenna. You may
need to optimize some of these parameters. Refer to the individual parameter setting information in the Setup section
of your ACU manual.
PARAMETER C-Band
DishScan®
Ku-Band
DishScan®
My Parameters
EL TRIM
0
AZ TRIM
0
AUTO THRES
100
EL STEP SIZE
0
AZ STEP SIZE
0
STEP INTEGRAL
0
SEARCH INC
30
15
SEARCH LIMIT
200
100
SEARCH DELAY
30
SWEEP INC
0040
SYSTEM TYPE
0005
GYRO TYPE
2
POL TYPE
72
POL OFFSET
30
POL SCALE
90
AZ LIMIT 1
0
AZ LIMIT 2
0
EL LIMIT 12
0
AZ LIMIT 3
0
AZ LIMIT 4
0
EL LIMIT 34
0
AZ LIMIT 5
0
AZ LIMIT 6
0
EL LIMIT 56 0
5V OFFSET 0
5V SCALE 0
TRACK DISP
Refer to TRACK DISP parameter
TX POLARITY
2
REMOTE PARAMETER ST94-21 ST94-21 ST144-21
PCU Configuration Number N0xxx 212 213 208
DishScan Phase/Gain N7xxx
149
149
192
Home Flag Offset N6xxx 000 000 000
