Secure Sprint 211 User Manual

Display Super-twisted Nematic (STN) LCD with backlight
2 Electrical Connection, Supply 3 Phase, 4 Wire, Direct Connected
Voltage measuring
element
Voltage divider
Current measuring
element
CT
Measuring Elements Three
Reference Voltage
(Supply Voltage)
230V± 20%
Reference current range 10A Ib, 100A Imax (per phase)
Frequency 50 Hz ±5%
EMC/Electric Surge
BS EN 50470-1, 50470-3
Metrology LED
Two LEDs, 1000 pulses/unit
RJ45 port/connector Option not accessible
Load control contactor 230 VAC, 100A
Non-volatile memory 2MB Flash, Data retention up to 15 years
Connecting Cables
(Recommended -As per
service and installation
practices)
Type PVC, V-75,
Copper
PVC, V-90,
Copper
Size
35mm
2
for 100A 35mm
2
for 100A
Voltage rating
600/1000V
600/1000V
Normal
temperature rating
75°C 90°C
Communication module
Nominal Voltage: 4V(+/-0.1V)
Maximum load: 1.4A (Peak)
3 Protection Dielectric Strength • AC voltage withstands as per BS EN 50470-1
• Impulse withstand as per BS EN 50470-1
4 Compliance Metrology
BS EN 50470-1, 50470-3 Class B
Power Consumption
BS EN 50470-1, 50470-3
BGX701-160-R01 Sprint 211 Installation Manual Page 13 of 48
