3 Meter specifications
This section describes the mechanical, electrical, compliance, hardware and environmental specifications for
the Sprint 211 meter.
3.1 General specifications
S. No. Specification Description
1 Mechanical Dimensions (mm) 221 (H) x 180 (W) x 116 (D)
Weight 2.2 kg approx (Actual weight may vary with variants)
Mounting Projection type
Front cover
Translucent PC-FR grade V0
Base Opaque, PC-FR material
Communication module
cover
Opaque, PC-FR material
Terminal cover
Opaque, PC-FR material
Secondary terminal
cover
Opaque, PC-FR material
Terminal block Opaque 10% glass filled PC-FR grade V0, matt finish
Rating plate
Opaque, PC-FR material
Main load terminal
screws
Nickel plated M8 brass grub, optional nickel plated M8
Pozidriv PZ#3
Current bus-bars
(Internal)
Made of copper with tin plating
Minimum bore diameter
for main terminals
11 mm, suitable for 35 mm
2
multi-strand copper cables
Sealing Provision
• 2 seals at the back of the meter (upper screws)
• 2 seals under the terminal cover
• 2 seals on the terminal cover
• 1 optional seal for configuration button
• 2 seals on the module
Sealing screw Captive type, made of brass, sealing hole diameter 2mm
Page 12 of 48 Sprint 211 Installation Manual BGX701-160-R01
