Secure Sprint 211 User Manual

Table 3: Recommended mounting screws
S. No Position for use Screw
type
No. of
screws
Screw
material
Recommended torque
(in Nm)
1.
Top Mounting Hole AB8 1 - -
2.
Bottom Mounting Holes (Oblong) M4 2 Steel 1.2
4.6.4 Selecting the cable
Given below is a general cable chart with details on current carrying capacity using different conductors.
Table 4: Cable selection chart
S. No Cross section area (mm
2
) Current range :
Copper conductor (in
Amperes)
Current range :
Aluminium conductor (in
Amperes)
1.
4 26 23
2.
6 33 30
3.
10 45 39
4.
16 60 50
5.
25 75 -
6.
35 95 -
7.
50 125 -
 This is a general chart and the installer may refer to vendor
specification for the accurate details.
 Copper cable is highly recommended for current ratings above 50
ampere.
Page 22 of 48 Sprint 211 Installation Manual BGX701-160-R01
