Port Settings
Print Server User Manual Windows 53
The option 'PJL' may not be enabled at the same time.
What do you want
to do?
 ’Enabling 1284.4/MLC via the Print Server Homepage’ 53
 ’Enabling 1284.4/MLC via InterCon-NetTool’ 53
Enabling 1284.4/MLC via the Print Server Homepage
Proceed as follows:
1. Start the Print Server Homepage.
2. Select Configuration – Printer Port.
3. Tick 1284.4/MLC.
4. Click Save to confirm.
 The setting will be saved.
Enabling 1284.4/MLC via InterCon-NetTool
Requirements
 The InterCon-NetTool is installed on the client, see: 15.
Proceed as follows:
1. Start the InterCon-NetTool.
2. Double-click the print server in the device list.
The Properties dialog appears.
3. Select Configuration – Printer Port.
4. Tick 1284.4/MLC.
5. Click OK to confirm.
 The setting will be saved.
