Sekonic C-7000 SDK User Manual

C-7000 SDK REFERENCE MANUAL
No. I401-C-700-034
Page 20
2012/03/01
3.7.8. SK_StopStandby ()
opeartion
Forcibly stop 90 seconds stanby for flash measuremnt in case of cordless flash
measurement
type
Function SK_StopStandby() as Long
argument
none
return
value
Result of communication with C-7000 (refer3.5.1)
note
example
Private C7000Device As New C7000.SDK ' generate instance of SDK
Private Sub Sample()
Dim SDKResult As Long
' >>>>> start measurement <<<<<
SDKResult = C7000Device.SK_StartMeasuring ()
If C7000.SDK.SKF_STATUS_COM.SUCCESS <> SDKResult Then ' start measurement
error ?!
' add error processing...
End If
' >>>>> stop stanby <<<<<
SDKResult = C7000Device.SK_StopStandby()
If C7000.SDK.SKF_STATUS_COM.SUCCESS <> SDKResult Then ' stop standby
error ?!
' add error processing...
End If
End Sub
