MRD 5800 – User Manual
Page 44 (116)
Blue, Green, Gray
is the color of the video the MRD will output.
4x3 Output Aspect
Ratio Auto Conversion
Disabled
AFD
If 4x3 Auto Conversion is set to Disabled the
MRD 5800 uses the 4x3 Conversion Mode
setting to format video. If 4x3 Auto
Conversion is set to AFD the MRD 5800 will
apply the conversion defined by the AFD
code in the incoming stream. If 4x3 Auto
Conversion is set to AFD, but the AFD code
is not present or invalid in the incoming
stream the 4x3 Conversion Mode setting will
be used.
4x3 Output Aspect
Ratio Conversion
Mode
Center-Cut
Letterbox
Anamorphic
Center-Cut cuts off top and bottom of the
video. Letterbox adds bars at the top and
bottom of the video. Anamorphic stretches
the video height and width to match the
format mode.
16x9 Output Aspect
Ratio Auto Conversion
Disabled
AFD
If 16x9 Auto Conversion is set to Disabled
the MRD 5800 uses the 16x9 Conversion
Mode setting to format video. If 16x9 Auto
Conversion is set to AFD the MRD 5800 will
apply the conversion defined by the AFD
code in the incoming stream. If 16x9 Auto
Conversion is set to AFD, but the AFD code
is not present or invalid in the incoming
stream the 16x9 Conversion Mode setting
will be used.
16x9 Output Aspect
Ratio Conversion
Mode
Center-Cut
Pillarbox
Anamorphic
Center-Cut cuts off the sides of the video.
Pillarbox adds bars at the left and right of the
video. Anamorphic stretches the video height
and width to match the format mode.
Overlay Type
None
Closed Captions
DVB Subtitles
Teletext Subtitles
Closed Captions overlays burns closed
captioning in the video output. DVB Subtitles
burns subtitles in video output. Teletext
Subtitles burns subtitles in the video output.
None disables overlays completely.
Closed Caption
NTSC
DTVCC
Sets the type of closed captions that will be
in the overlay.
NTSC Service
CC1 – CC4
Sets the NTSC closed caption service that
will be displayed in the overlay. This setting
is only available if the Closed Caption option
is set to NTSC.
DTVCC Service
Service 1-6
Sets the DTVCC closed caption service that
will be displayed in the overlay. This setting
is only available if the Closed Caption option
is set to DTVCC.
DVB Subtitles
Language Codes
If DVB Subtitles overlays are enabled this
setting choosing the language which the
subtitles are displayed. Only the languages
present in the stream are given.
