MRD 5800 – User Manual
Page 72 (116)
range can be used, but it is good practice to always
choose a port >1030 and an even number
Source Port
0 - 65535
This is the port used by the MRD 5800 to transmit
the MPEG/IP stream.
TS Packets Per IP
Packet
1-7
The number of TS packets that are contained with
a single IP packet. Default is 7. Lowering this value
below default increases network overheard.
Differentiated
Services
Default
Assured Forwarding
1-1 to 4-3
Expedited
Forwarding
Define the quality of service (QoS) classification the
packets carry when transmitted.
Encapsulation
UDP
RTP
Sets the Encapsulation to UDP or RTP.
FEC
Off
Columns
Colums/Rows
Sets the FEC Type or disables FEC.
FEC Columns
1-20 (Columns)
4-20 (Columns/Rows)
Defines the number of Columns used to construct
the FEC Matrix. (Columns * Rows must be ≤ 100.)
FEC Rows
4-20
Defines the number of Rows used to construct the
FEC Matrix. (Columns * Rows must be ≤ 100.)
4.2.28 Configuring the MPEG/IP MPE Outputs
This menu allows the user to configure the MPEG/IP Multi-Protocol Encapsulation
(MPE) outputs. Each MPE Output allows the user to select an MPE data PID from the
transport stream to be output.
